A Loom 140 Dia likely refers to a type of loom cable ducting system with a diameter of 140 mm, used primarily in railway and industrial applications to protect and organize electrical cables. These loom systems are essential for keeping cables safe from physical damage, moisture, dirt, and other environmental factors while also ensuring easy management and accessibility for maintenance and repairs.
Key Features of Loom 140 Dia:
- Diameter:
- 140 mm: The “140 Dia” indicates that the loom has a 140 mm diameter, which allows it to accommodate a large number of electrical cables or thicker cables, making it suitable for applications that require substantial cable management.
- Material:
- High-Density Polyethylene (HDPE) or PVC: These loom systems are usually made from durable materials like HDPE or PVC, which offer flexibility, resistance to environmental factors like moisture, and protection against mechanical damage.
- Flame Retardant: Some looms are designed with flame-retardant materials to minimize the risk of fire, especially in high-risk environments like railways.
- Applications:
- Railway Systems: In railways, loom systems are used to organize and protect electrical cables that run along tracks, under platforms, or within signaling systems. The loom ensures that cables are properly shielded from environmental factors, physical wear, and interference from moving parts.
- Industrial Installations: Looms are also commonly used in industrial plants to protect power and communication cables in areas where they may be exposed to harsh conditions or need to be bundled together for safety and efficiency.
- Design:
- Flexible or Rigid: Looms can be flexible, allowing them to bend around corners and obstacles, or rigid, providing additional strength and protection in areas subject to heavy mechanical loads.
- Smooth or Corrugated: Some looms feature smooth surfaces for ease of installation and maintenance, while others have a corrugated design for added strength and flexibility.
- Protection:
- Environmental Resistance: Looms protect cables from moisture, dust, chemicals, and UV rays, ensuring long-lasting performance even in harsh outdoor environments like rail tracks.
- Mechanical Protection: The loom prevents physical damage to the cables from external forces such as vibration, impact, or abrasion.
- Installation:
- Easy Access: Looms are designed for easy access, allowing maintenance personnel to open the duct for inspection, repairs, or the addition of new cables without disturbing the entire system.
- Support Brackets: In many installations, support brackets or clamps are used to securely fasten the loom in place, preventing it from shifting or sagging under the weight of the cables.
